Optional square grille can be used with this model.
Frequency Response | 50 Hz — 30 kHz |
Sensitivity (1W@1M) | 89 dB |
Nominal Impedance | 8 ohms |
Maximum SPL | 109 dBA |
Power Handling (RMS) | 100 W |
Recommended Amplifier Requirements | 20 — 100 W |
Drivers | 8" C-CAM cone bass driver, 1" C-CAM Gold Dome tweeter (fixed angle) |
Controls | HF Level Switch (+3 dB / 0 dB / -3 dB) - Adjustable at the point of installation |
Adjustment Controls | 2 x (1 pair) Gold plated push style terminal |
Overall Diameter (Including Grille) | 285 mm (111/4") |
Overall Depth (Including Grille) | 102.5 mm (41/32") |
Cut-Out Hole Diameter | 247 mm (93/4") |
Mounting Depth | 97.55 mm (37/8") |
Optional Square Grille - Outer Dimensions | 285 x 285 mm (111/4") |
Fixing Type | 3 position Tri-Grip dog leg fixings |
Construction Material | Mineral Filled PC-ABS Polymer (UL V0 Fire Retardant, RoHS2 Compliant) |
Grille | SS430 Stainless Steel |
Magnets | Samarium Cobalt |
Operating Temperature Range | -34° to 79° C -29° to 174° F |
Weight | 2.8 kg (6 lb 2 oz) |
Pre-Construction Bracket | CB8 Pre-Construction Bracket (Green) |
Back Box | CCBOX-R | CMBOX-R |
Product Weight (lbs.) | 6.13 |
Frequency Response | 50 Hz — 30 kHz |
Outdoor Approved | Yes |
Manufacturer Warranty | Limited Lifetime |
RMS Power Handling (Watts) | 100 |
Color | Black/Orange |
Impedance | 8 ohms |
Maximum Power Handling (Watts) | 100 |
Number of Speakers | 1 |
Sensitivity | 89 |
Speaker Type | In-Ceiling Speakers |
